Description :
◆ All-aluminum body, fanless and cable-free design;
◆ Support Alder Lake-N series processors;
◆ 1 x DDR5 SO-DIMM, total maximum 16GB;
◆ HDMI display, RS232 CONSOLE, TPM2.0 optional;
◆ 6 x 2.5G networks, B-Key, E-Key;
◆ M.2 2280 SATA for option;
◆ DC 12-19V;
◆ Size: 178 x 121 x 55 mm;
|
Model |
N-BOX-S3 |
|
Size |
Machine size: 178 x 121 x 55mm |
|
Material |
All-aluminum, fanless and cable-free design |
|
Color |
Iron Gray |
|
Processor support |
Support Alder Lake-N series processors |
|
Network card |
6 x Intel 2.5G networks, POE optional |
|
Memory |
1 x DDR5 SO-DIMM, total maximum 16GB |
|
Storage |
1 x SATA3.0, supports 2.5-inch HDD |
|
|
1 x M.2 2280 SATA |
|
Other |
E-Key WIFI/BT and B-Key 4G/5G modules optional, external antenna |
|
|
TPM2.0 optional |
|
I/o interface |
1 x switch button; 1 x reset button; 1 x hard disk indicator light; 1 x power indicator light |
|
|
6 x RJ45 network ports |
|
|
1 x HDMI port |
|
|
1 x DC power port |
|
|
4 x USB 3.0 ports |
|
|
1 x RS232 RJ45 interface |
|
|
2 x antenna ports |
|
Power supply |
DC 12-19V, 60W |
|
OS support |
Windows10, Windows11, Linux, etc. |
|
Unit weight |
Net weight: about 1150g |
